2T VMAX Four Wheel Electric Forklift Truck For Construction And Industrial Use
electric lift truck Quick Details
Brand Name:Vmax
Model Number:CPD20
Type:Powered Pallet Truck
Power Souce:AC Motor
Rated Loading Capacity:2000kg
Max. Lifting Height:6000mm
Min. Lifting Height:3000mm
Fork Length:1070mm
Fork Width:120mm
Overall Dimensions:2349*1265*2125mm
Certification:CE ISO TUV GS BV
After-sales Service Provided:Engineers available to service machinery overseas
Color:per your request
Weight:4160kg
electric lift truck specification:
| Characteristics |
| 1 |
4-wheel AC Power Pneumatic Tire Electric Forklift |
|
CPD20 |
CPD25 |
| 2 |
Capacity |
at rated load center |
kg |
2000 |
2500 |
| at load center - distance |
mm |
500 |
| 3 |
Power |
diesel, Gasoline / LPG, electric |
|
electric |
| 4 |
Tire Type |
solid, pneumatic |
|
pneumatic |
| 5 |
Wheels (x = drive) |
number front / rear |
|
2x/2 |
| Dimensions |
| 6 |
Lift Height with standard two-stage mast (VM) |
mm |
3000 |
| 7 |
Free Lift Height |
mm |
140 |
140 |
| 8 |
Fork size |
Length*Width*Thickness |
mm |
1070x120x40 |
1070x120x45 |
| 9 |
Fork spacing (Min./Max.) |
out-to-out |
mm |
240/1040 |
240/1040 |
| 10 |
Mast tilt angle |
Forward / Backward |
deg |
6/10 |
| 11 |
Overall dimensions |
length (to fork face) |
mm |
2349 |
2381 |
| width (standard) |
mm |
1265 |
| height |
with lowered mast |
mm |
2040 |
| with extended mast |
mm |
4240 |
| to top of overhead guard |
mm |
2125 |
| 12 |
Turning radius (outside) |
mm |
2050 |
2100 |
| 13 |
Load distance (centerline of front axle to front face of forks) |
mm |
459 |
464 |
| Performance |
| 15 |
Speeds |
Travel speed |
loaded |
km/h |
12 |
12 |
| 16 |
empty |
km/h |
14 |
14 |
| 17 |
Lifting speed |
loaded |
mm/sec |
310 |
300 |
| 18 |
empty |
mm/sec |
420 |
420 |
| 19 |
Gradeability |
loaded/empty |
% |
10 |
| Weight |
| 20 |
empty |
with minimum weight battery |
|
Kg |
4160 |
4360 |
| Chassis |
| 21 |
Tyre Size |
Front, standard pneumatic tires |
|
23x9-10-16PR |
| 22 |
Rear, standard pneumatic tires |
|
18x7-8-14PR |
| 23 |
Wheel base |
mm |
1500 |
| 24 |
Tread width |
Front |
mm |
1040 |
| Rear |
mm |
950 |
| 25 |
Min. Under-clearance (full load / no load ) |
at lowest point at mast |
mm |
85/105 |
| 26 |
at center of wheelbase |
mm |
120/140 |
| Powertrain |
| 27 |
Battery |
Voltage |
V |
48 |
| 28 |
Capacity |
AH |
630/700 |
630/700 |
| 29 |
Electric motor |
Drive motor output |
kw/rpm |
8/1300 |
| 30 |
Hydraulic motor output |
kw/rpm |
15/2200 |
15/2200 |
| 31 |
controller |
|
American(USA CURTIS electric controller ) / American GE, GE/Italian SME AC controller |
