4 Ton Automated Forklift Trucks With Isuzu C240 Engine Industrial Usage
4.0 Ton Automatic Diesel Forklift Trucks With Isuzu C240 engine
Load capacity 4000kg with Isuzu c240 engine. 3M lift height,1.07m fork,solid tyres.Automatic,12months warranty.Equipped with China engine C490BPG,Hydraulic transmission with TCM-technology. Standard with 2-stage wide-view mast, lifting height is 3,000mm.Pneumatic tires, 1070mm forks,Safety seat,Free tool box and spare parts.Back-up buzze, rearview mirror, full set of lights and so on.
Automated Forklift Trucks Quick Details
Brand Name:Vmax
Model Number:CPCD40
Type:Powered Pallet Truck
Power Souce:Diesel Engine
Rated Loading Capacity:4000kg
Max. Lifting Height:6000mm
Min. Lifting Height:3000mm
Fork Length:1070mm
Fork Width:130mm
Overall Dimensions:3M lift height,1.07m fork,solid tyres.
Certification:ISO&CE certificate
After-sales Service Provided:Engineers available to service machinery overseas
Color:Red yellow
package:2sets/20GP
OEM:offered
Automated Forklift Trucks Specifications
| 3T COUNTER BALANCE DIESEL FORKLIFT TRUCK SPECIFICATION |
| Model |
Unit |
CPC40/CPCD40 |
| Power type |
|
Diesel |
| Rated capacity |
kg |
4000 |
| Load center |
mm |
500 |
| Mast Lifting height |
mm |
3000 |
| Free lift height |
mm |
175 |
| Fork size(L*W*T) |
mm |
1070×125×45 |
| Tilting Angles(Front/Rear) |
deg |
6°/12° |
| Front overhang |
mm |
485 |
Exterior Size |
Length without fork |
mm |
2680 |
| Overall width |
mm |
1225 |
| Mast drop |
mm |
2065 |
| Max.lift |
mm |
4250 |
| Front-wheel Overhead |
mm |
2070 |
| Min Turning Radius |
mm |
2420 |
| Min.intersecting aisle |
mm |
2100 |
Speeds |
Max Driving speeds |
km/h |
18.5/20 |
| Lifting speeds |
mm/s |
470/520 |
| Lowering speeds |
mm/s |
550/520 |
| Max.grade ability |
% |
20 |
| Total weight |
kg |
4300 |
Tires |
Front |
|
28*9-15-12PR |
| Rear |
|
6.5-10-10PR |
| Wheelbase |
mm |
1700 |
Tread |
Front |
mm |
1000 |
| Rear |
mm |
970 |
| Min.ground clearance |
mm |
110 |
Engine |
Model |
|
XINCHANG490BPG |
| Rated output |
kw/rpm |
37/2650 |
| Rated torque |
N.m/rpm |
148/1800 |
| No.of cylinder |
|
4 |
| Displacement |
L |
2.54 |
| Fuel tank capacity |
L |
52
|
