battery forklift truck 24V Stand-on ,1ton-2ton AC electric/battery reach truck
VFA Series rated Load Capacity: 2000kg, lift height: 5000mm;
1. Speed Limited for high position, to avoid the possibility of products' overturning when high speed in high position;
2. Curve safe control, the forklift will reduce the speed automatic when turning, to aviod the ejection of operator and products from the vehicle by the high speed;
3. Regenerative braking function to reduce the operation cost;
4. Safe cutoff valve, to protect the operator and goods in well condition;
5. Shock Absorption of Pedal,to ensure the comfortable of working and reduce the fatigue;
6. Reinforced Mast,to ensure the mast are not out of shape and lift the goods smoothly;
7. Ergonomics multi-functional operation handle.
battery forklift truck specification:
| 24v Electric Reach truck |
| Description |
VFA10-16 |
VFA10-25 |
VFA10-30 |
VFA10-35 |
VFA15-25 |
VFA15-30 |
VFA20-16 |
| Model No. |
| Load Capacity (KG) |
1000 |
1000 |
1000 |
1000 |
1500 |
1500 |
2000 |
| Load center MM |
500 |
500 |
500 |
500 |
500 |
500 |
500 |
| Max. Lifting Height (MM) |
1600 |
2500 |
3000 |
3500 |
2500 |
3000 |
1600 |
| Tyre |
Solid tyre |
Solid tyre |
Solid tyre |
Solid tyre |
Solid tyre |
Solid tyre |
Solid tyre |
| Reach Stroke (MM) |
550 |
550 |
550 |
550 |
650 |
650 |
700 |
| Fork Size LxW (MM) |
1070*100 |
1070*100 |
1070*100 |
1070*100 |
1070*100 |
1070*120 |
| Between Forks (MM) |
220-600 |
220-600 |
220-600 |
220-600 |
220-600 |
220-600 |
260-660 |
| Overall Length without pedal (MM) |
2290 |
2290 |
2290 |
2290 |
2375 |
2375 |
2460 |
| Overall Width (MM) |
1090 |
1090 |
1090 |
1090 |
1090 |
1090 |
1090 |
| Height (MM)-Mast Lowered |
2140 |
1850 |
2100 |
2350 |
1850 |
2100 |
2140 |
| Height (MM)-Mast Extended |
2460 |
3360 |
3860 |
4360 |
3360 |
3860 |
2460 |
| Min. Turning Radius(MM) |
1630 |
1630 |
1630 |
1630 |
1800 |
1800 |
1930 |
| Travel Speed km/h-Laden/unladen |
4.0/5.0 |
4.0/5.0 |
4.0/5.0 |
4.0/5.0 |
4.0/5.0 |
4.0/5.0 |
4.0/5.0 |
| Min.Stacking Aisle(MM) (1000*1000 Pallet) |
2590 |
2590 |
2590 |
2590 |
2715 |
2715 |
2840 |
| Length of Pedal(mm) |
500 |
500 |
500 |
500 |
500 |
500 |
500 |
| Grade Ability % |
5-8 |
5-8 |
5-8 |
5-8 |
5-8 |
5-8 |
5-8 |
| Driving Wheel (MM) |
φ215*75 |
| Front Wheel (MM) |
φ267*114 |
| Balance Wheel (MM) |
φ150*50 |
| Battery V/Ah |
24/210 |
| Charger V/A |
24/30 |
| Driving Motor (KW) |
1.2 |
1.2 |
| Lifting Motor (KW) |
2 |
2 |
2 |
| Service Weight (with battery) KG |
1800 |
1840 |
1860 |
1880 |
1860 |
1880 |
1970 |
battery forklift truck Packaging & Shipping
A: Date of delivery: 15-25days after received the deposit
B: Payment terms: T/T(30% deposit, balance paid before shipment). Or L/C at sight
C: Guaranty period: One year or 2000hours upon receiving goods.
Our Services
As a professional manufacturer of forklift, we also can offer you customized service,
The following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m
Side shifter, fork positioner, longer forks, fork extension
For the details of customized configurations and options, please contact with us.
VMAX professional service will be impressed on you.
