Counter Balance LPG Forklifts Used In Warehouses With Nissan K21 Engine
Gasoline Powered Forklift 2TON :STANDARD INSTALLMENT:
CPQYD20: Load capacity 2000kg,hydraulic transmission,3m 2 stage duplex mast,
gasoline engine NISSAN K21, 920mm fork, Electronic gear transmission, key switch,
Pneumatic tyres,Safety seat,Free tool box and spare parts.
Gasoline Powered Forklift OPTION:
As a professional manufacturer of forklift, we also can offer you customized service,
the following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m
side shifter, fork positioner,longer forks, fork extension
For the details of customized configurations and options, please contact with us.
VMAX professional service will be impressed on you.
OTHERS :
A: date of delivery:15-25days after received the deposit
B: payment terms:T/T(30% deposit,balance paid before shipment).Or L/C at sight
C: Guaranty period: one year or 2000hours upon receiving goods.
Gasoline Powered Forklift specification:
| Model |
|
CPQYD20 |
| Load capacity |
kg |
2000 |
| Load center |
mm/s |
500 |
| Power type |
|
Gasoline/LPG/CNG |
| Max. lifting speeds |
mm/s |
400 |
| Max. Driving speeds |
km/h |
17/19 |
| Max. Towing |
kN |
14/9 |
| Grade ability |
% |
15/20 |
| H1 Lifting height |
mm |
3000 |
| Free lift |
mm |
60 |
| Tilting angles |
|
6/12 |
| Min.turning radius |
mm |
2425 |
| Min.right angle aisle width |
mm |
2050 |
| Min.under-clearance |
mm |
110 |
| Dimensions |
A Overall length |
mm |
3580 |
| B Overall width |
mm |
1160 |
| H Overall height |
mm |
2095 |
| H2 Overall height |
mm |
4080 |
| Tyre |
Front tyre |
|
7.00-12 |
| Rear tyre |
|
6.00-9 |
| Total weight |
kg |
3320 |
| Engine |
Engine model |
|
NISSAN K21 |
| Rate Power |
KW |
37/36 |
| Rotate Speed At Rate power |
rpm |
2650/2400 |
| Max. torque |
Nm |
≥148 |
| Rotate speed at max torque |
rpm |
1800-1900 |
| Type of power shift |
|
Clutch |
Tor-con |
