Heavy Duty Diesel Powered Forklift / Four Wheel Drive Forklift Battery Green Power
Product Details:
Place of Origin:
ANHUI,CHINA
Brand Name:
VMAX
Certification:
CE,SGS,BV
Model Number:
cpcd30
Payment & Shipping Terms:
Minimum Order Quantity:
1UNIT
Price:
Negotiable
Packaging Details:
bubble wrap
Delivery Time:
45 DAYS
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
3000unit / year
Contact Now
Detailed Product Description
Power:
Diesel
Color:
Red
Product Name:
Diesel Engine Forklift Truck
Fork Length:
1070mm
Fork Width:
125mm
Overall Dimensions:
6.796CBM
High Light:
3 wheel electric forklift , warehouse stand up forklift
Heavy Duty Diesel Powered Forklift / Four Wheel Drive Forklift Battery Green Power
The diesel forklift equipment with PERKINS engine, hydraulic transmission, double oil pump, hydraulic assisted steering, front double tires. It is widely used to handing all kinds of goods, such as pallet,steel,brick etc.
Exterior Size Length without fork mm 2680
Overall width mm 1225
Mast drop mm 2065
Max.lift mm 4250
Front-wheel Overhead mm 2070
Min Turning Radius mm 2420
Min.intersecting aisle mm 2100
Speeds Max Driving speeds km/h 18.5/20
Lifting speeds mm/s 470/520
Lowering speeds mm/s 550/520
Max.grade ability % 20
Total weight kg 4300
Tires Front
28*9-15-12PR
Rear
6.5-10-10PR
Wheelbase mm 1700
Tread Front mm 1000
Rear mm 970
Min.ground clearance mm 110
Engine Model
490BPG
Rated output kw/rpm 37/2650
Rated torque N.m/rpm 148/1800
No.of cylinder
4
Displacement L 2.54
Fuel tank capacity L 52
3T COUNTER BALANCE DIESEL FORKLIFT
Model Unit CPC30/CPCD30
Power type
Diesel
Rated capacity kg 3000
Load center mm 500
Mast Lifting height mm 3000
Free lift height mm 175
Fork size(L*W*T) mm 1070×125×45
Tilting Angles(Front/Rear) deg 6°/12°
Front overhang mm 485
