High Small Narrow Aisle Reach Truck , Counterbalance Fork Truck With 3m Lifting Height
Diesel forklift truck Counterbalance Forklift Truck with 4000kg load capacity
Model Number: CPCD40
Equipped with China engine XingchangC485BPG, Hydraulic transmission with TCM-technology
Standard with 2-stage wide-view mast, lifting height is 3, 000mm
Pneumatic tires, 1220mm forks, Safety seat, Free tool box and spare parts.
Back-up buzze, rearview mirror, full set of lights and so on.
Counterbalance Forklift Truck Description
| Model |
|
CPCD25 |
CPCD30 |
CPCD35 |
CPCD40 |
CPCD45 |
| Power type |
|
Diesel |
| Rated capacity |
kg |
2500 |
3000 |
3500 |
4000 |
4500 |
| Load center |
mm |
500 |
| Mast lifting height |
mm |
3000 |
| Fork size |
LxWxT |
mm |
1070x122x40 |
1070x125x45 |
1070x125x50 |
1070x130x50 |
1070x150x50 |
| Tilting/angles |
Front/
rear
|
|
6/12 |
| Min.Turing Radius |
mm |
2240 |
2420 |
2420 |
2700 |
2780 |
| Min.intersecting aisel |
mm |
2010 |
2100 |
2235 |
2685 |
3365 |
| Min.ground clearance |
mm |
120 |
110 |
125 |
130 |
160 |
| Overhead guard height |
mm |
2070 |
2070 |
2090 |
2105 |
2290 |
| Front overhang |
mm |
465 |
477 |
490 |
500 |
565 |
| Max. driving speeds |
Km/h |
19 |
18.5/20 |
19 |
18/19 |
20/19 |
| Max. lifting speeds |
Mm/s |
550 |
520 |
350 |
380 |
450 |
| Max. grade ability |
% |
20 |
20 |
20 |
20 |
20 |
| Length without fork |
mm |
2550 |
2680 |
2700 |
2895 |
3105 |
| Overall width |
mm |
1150 |
1225 |
1225 |
1410 |
1480 |
| Max. lift |
mm |
4030 |
4250 |
4250 |
4275 |
4280 |
| Tires |
Front |
mm |
7-12-12PR |
28*9-15-12PR |
28*9-15-12PR |
250-15-16PR |
300-15-18PR |
| Rear |
mm |
6-9-10PR |
6.5-10-10PR |
6.5-10-10PR |
6.5-10-10PR |
7-12-12PR |
| Wheelbase |
mm |
1600 |
1700 |
1700 |
1900 |
2000 |
| Tread |
Front/ Rear |
mm |
970/970 |
1000/970 |
1000/970 |
1160/1065 |
1180/1190 |
| Self-possessed |
kg |
3700 |
4300 |
4900 |
5310 |
6400 |
| Battery |
Voltage/Volume |
V/Ah |
12/80 |
12/80 |
12/80 |
12/80 |
12/80 |
|
Engine
|
Model |
|
XinchangC490BP |
XinchangC490BPG |
Xinchnag
A495BP
|
Xinchang
A498BP
|
Yituo LR4B3-G |
| Rated output |
kw/r.p.m |
37/2650 |
37/2650 |
42/2650 |
45/2650 |
61/2200 |
| Rated torque |
Nm/r.p.m |
148/1800 |
148/1800 |
174/1800-1900 |
198/1800 |
288/1600 |
| No.of cylinder |
|
4 |
4 |
4 |
4 |
4 |
| Displacement |
L |
2.54 |
2.54 |
2.98 |
3.168 |
4.58 |
| Fuel tank capacity |
L |
60 |
60 |
60 |
70 |
80 |
Counterbalance Forklift Truck Packaging & Shipping
A: Date of delivery: 15-25days after received the deposit
B: Payment terms: T/T(30% deposit, balance paid before shipment). Or L/C at sight
C: Guaranty period: One year or 2000hours upon receiving goods.
