Manual Operation Diesel Engine Forklift 4500kgs Loading Capacity 3105 * 2290 * 1480mm
Product Details:
| Place of Origin: |
CN |
| Brand Name: |
VMAX |
| Certification: |
CE,BV,SGS,ISO9001 |
| Model Number: |
CPC45 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1 unit |
| Price: |
＄13,870.00-＄18,500.00/unit |
| Packaging Details: |
nude package |
| Delivery Time: |
25-30 days |
| Payment Terms: |
L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: |
5,000 units/year |
Contact Now
Detailed Product Description
| Condition: |
New |
Power Souce: |
Diesel Engine |
| Fork Length: |
1070mm |
Fork Width: |
150mm |
| Transmission: |
Manual |
Overall Dimensions: |
3105*2290*1480mm |
| Max. Lifting Height: |
6000mm |
Certification: |
CE, BV,SGS,ISO9001 |
| Color: |
Optional |
Warranty: |
1 Year Or 2000 Hours |
| Engine: |
Mitsubishi, Xinchang, Dachai, Yanmar Etc |
Load Center: |
500mm |
| Loading Capacity: |
4500kgs |
| High Light: |
warehouse stand up forklift, four wheel drive forklift |
manual operation Japanese engine 4.5 ton diesel forklift with CE ISO90001 certificate:
| SPECIFICATIONS of VMAX diesel Forklift |
| Manufacturer's Data and Desigh Characteristics |
| Specifications |
| 1 |
Manufacturer |
|
|
| 2 |
Model |
Unit |
CPC45 |
| 3 |
Power type |
|
DIESEL |
| 4 |
Rated capacity |
kg |
4500 |
| 5 |
Load center |
mm |
500 |
| 6 |
Operator type |
|
|
| Size |
| 7 |
Max. lift height of mast with Load-backrest |
mm |
4280 |
| 8 |
Max.lift height of fork |
mm |
3000 |
| 9 |
Height of mast |
mm |
2330 |
| 10 |
Free lift height(with backrest) |
mm |
150 |
| 11 |
Height of Load-backrest |
mm |
1195 |
| 12 |
Distance from seat to overhead guard |
|
mm |
1000 |
| 13 |
overhead guard height |
|
mm |
2290 |
| 14 |
Length without fork |
mm |
3105 |
| 15 |
Front overhang |
mm |
565 |
| 16 |
Rear overhang |
mm |
540 |
| 17 |
Wheel base |
mm |
2000 |
| 18 |
The height of traction pin |
mm |
350 |
| 19 |
Min. ground clearance |
mm |
160 |
| 20 |
Overall width |
mm |
1480 |
| 21 |
The distance between forks |
|
mm |
1370/300 |
| 22 |
Tread(front /rear) |
|
mm |
1180/1190 |
| 23 |
Min. Turning radius(outside) |
mm |
2780 |
| 24 |
Min. Turning radius(inside) |
mm |
270 |
| 25 |
Min. Intersecting aisle |
|
mm |
3365 |
| 26 |
Mast tilt angle |
deg |
|
| 27 |
Fork size |
mm |
1070*150*50 |
| Performance |
| 28 |
Speeds |
Max.Drive speeds(with/without full load) |
km/h |
18/19 |
| 29 |
Lifting speeds (with /without full load) |
mm/s |
400/450 |
| 30 |
Lowering speeds(with /without full load) |
mm/s |
350/400 |
| 31 |
Max. tractive force(with /without full load) |
KN |
20/19 |
| 32 |
Max.grade ability (with/without full load) |
% |
18/20 |
| Weight |
| 33 |
Total weight |
kg |
6400 |
| 34 |
Weight Distribution full load (front/ rear) |
|
kg |
9540/1360 |
| 35 |
Weight Distribution zero load(front / rear) |
|
kg |
2630/3770 |
| Wheels and Tyres |
| 36 |
Quantity of wheels |
|
|
|
| 37 |
Type of tyres |
|
|
|
| 38 |
Tires |
Front |
|
300-15-18PR |
| 39 |
Rear |
|
7.00-12-12PR |
| 40 |
Driving Brake |
|
|
| 41 |
Parking Brake |
|
|
| Control device for driving and transmitting |
| 42 |
Battery |
V/AH |
(12/80)*2 |
| 43 |
Engine (standard) |
Model |
|
XINCHANG 4D35G |
| 44 |
Rated output |
kw/rpm |
48/2200 |
| 45 |
Rated torque |
N.m/rpm |
230/1600-1800 |
| 46 |
No.of cylinder |
|
4-98X105 |
| 47 |
Displacement |
L |
3.46 |
| 48 |
Fuel tank capacity |
L |
80 |
| 49 |
Number of speeds for transmission |
|
|
