Red 10 Ton Diesel Powered Forklift / 10000kg Fork Lift Trucks Energy Saving
Product Details:
| Place of Origin: |
ANHUI,CHINA |
| Brand Name: |
VMAX |
| Certification: |
ce |
| Model Number: |
CPCD100 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1UNIT |
| Price: |
Negotiable |
| Packaging Details: |
bubble wrap |
| Delivery Time: |
45 DAYS |
| Payment Terms: |
L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: |
3000unit / year |
Contact Now
Detailed Product Description
| Color: |
Red |
Type: |
Diesel Forklift Truck |
| Name: |
Heavy Duty Forklift |
Max. Lifting Height: |
6000mm |
| Rated Loading Capacity: |
10000kg |
Power Souce: |
Diesel Engine |
| High Light: |
warehouse stand up forklift, four wheel drive forklift |
10 ton forklift Product Characteristics
- Integrated central control box the reliability of electric system
- Ergonomical design ensures best operation
- Energy saving hydraulic system decreases fuel consumption
- High-quality hydraulic hoses, no oil leakage
- Wide-view mast design improves the productivity and safety
- Forklift truck
10 ton diesel forklift truck specification:
| General |
Manufacturer |
|
ANHUI VMAX MACHINERY CO., LED. |
| Model |
|
CPCD80 |
CPCD100 |
| Power Unit |
|
Diesel |
| Rated Capacity |
kg |
8000 |
10000 |
| Load Center |
mm |
600 |
600 |
| Size |
Overall Max.Lifting Height (with backrest) |
mm |
4360 |
4085 |
| Max.Lifting Height |
mm |
3000 |
3000 |
| Height Mast Retracted (upright) |
mm |
2700 |
2850 |
| Free Lift Height |
mm |
200 |
200 |
| Backrest Height (from upper face of forks) |
mm |
1360 |
1015 |
| Overall Height (overhead guard) |
mm |
2560 |
2560 |
| Overall Length (W/O forks) |
mm |
5160/3940 |
5480/4260 |
| Wheel Base |
mm |
2500 |
2800 |
| Min. Ground Clearance Under Mast |
mm |
245 |
245 |
| Overall Width |
mm |
2165 |
2165 |
| Lateral Fork Adjustment Outside of Fork (Max./Min.) |
mm |
2000/340 |
2140/410 |
| Tread (front/rear) |
mm |
1600/1700 |
1600/1700 |
| Outside Turning Radius |
mm |
3700 |
3900 |
| Inside Turning Radius |
mm |
200 |
200 |
| Min.Intersecting Aisle |
mm |
3310 |
3540 |
| Tilting Angles (forward/backward) |
|
6°/12° |
6°/12° |
| Fork Dimensions |
mm |
70X1220X170 |
80X1220X175 |
| Service Mass |
kg |
10960 |
12510 |
| |
Max. Traveling Speeds (with/without load) |
km/h |
26/30 |
26/30 |
| Lifting Speeds (with/without load) |
mm/s |
440/470 |
360/380 |
| Lowering Speeds (with/without load) |
mm/s |
≤600/≥300 |
≤600/≥300 |
| Max. Draw-bar Pull with Load |
kN |
60 |
58 |
| Max. Negotiable Gradient (with/without load) |
% |
27/20 |
22/20 |
| Tyre |
Wheels Number Front/Rear (x=driven) |
|
4x/2 |
4x/2 |
| Tyre Type |
|
Pneumatic |
Pneumatic |
| Tyre Size (front) |
|
9.00-20-14PR |
9.00-20-14PR |
| Tyre Size (rear) |
|
9.00-20-14PR |
9.00-20-14PR |
| Engine |
Internal Combustion Engine Model |
|
ISUZU 6BG1QC-02 |
| Internal Combustion Engine Rated Output |
kW/rpm |
82/2200 |
| Internal Combustion Engine Rated Torque |
Nm/rpm |
415/1400-1600 |
| Engine Fuel Tank Capacity |
L |
140 |
