Safe And Reliable Electric Stacker Forklift CE / ISO9001 / SGS Approval
electric stacker forklift Quick Details
Brand Name:Vmax
Model Number:TBC15
Type:Powered Pallet Truck
Power Souce:AC Motor
Rated Loading Capacity:2000kg
Max. Lifting Height:1600KG/1800/2000
Min. Lifting Height:3000mm
Fork Length:920mm,1070mm
Fork Width:40MM (1.57 IN)
Overall Dimensions:2495*1270*2210*mm
Certification:ISO&CE&SGS certificate
After-sales Service Provided:Engineers available to service machinery overseas
Color:Red yellow
package:4sets/20GP
OEM:offered
electric stacker forklift specification:
1
Description
Electric Pallet Stacker
2
Model
TBE15-30
TBC15-25
TBC15-30
3
Kg Load capacity
1500
1500
1500
4
mm Load center
600
500
500
5
mm Max. lifting height
3000
2500
3000
6
mm Free lift
0
0
0
7
Wheel type
Polyurethane solid tire
8
(LxW)mm Fork size
1150*190
1100*190
1100*190
9
mm Width of forks
670
565
565
10
mm Overall length
2132
2100
2100
11
mm Overall width
940
800
800
12
mm
Overall height mast closed
2060
1720
1970
13
Overall height fork raised(with backrest)
3522
2900
3440
14
mm Outside turning radius
1705
1600
1600
15
mm Front wheel to fork tip
305
470
470
16
km/h Max. walking speeds
4.8
4.0
4.0
17
% Grade abitity
8
5
5
18
KgTotal weight( with battery)
~1350
~730
~750
19
mm Driving wheel
Φ230*65
Φ215*75
Φ215*75
20
mm Front wheel
Φ80*75
Φ80*70
Φ80*70
21
mm Balance wheel
Φ150*50
Φ150*50
Φ150*50
22
V/Ah Battery
24/360
24/210
24/210
23
V/A Charger
24/40
24/30
24/30
24
Kw Driving motor
1.1 AC
1.2
1.2
25
Kw Lifting motor
2.0
2.0
2.0
Our Services
As a professional manufacturer of forklift, we also can offer you customized service,
The following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m
Side shifter, fork positioner, longer forks, fork extension
For the details of customized configurations and options, please contact with us.
VMAX professional service will be impressed on you.
Packaging & Shipping
A: Date of delivery: 15-25days after received the deposit
B: Payment terms: T/T(30% deposit, balance paid before shipment). Or L/C at sight
C: Guaranty period: One year or 2000hours upon receiving goods.
